Hacking the Sonoff RF Bridge 433

Itead Studio has been releasing interesting gadgets for the Home Automation community based on a low price tag and extreme hackability. You can google “sonoff” (the main brand for Itead Studio home automation devices) to get more than a million hits, including official pages, reviews and lots of hacks. The ubiquitous ESP8266 (or its sibling ESP8285) is the core of all those devices, using WiFi instead of the traditional RF messages, replacing a remote with mobile apps or voice commands. But also, using custom firmwares like ESPurna, technologies and solutions like MQTT, Node-RED or Home Assistant. But one of the latests devices from the chinese firm tries to bridge the gap between those two technologies: the Sonoff RF Bridge 433.

Continue reading

20160820_102049x

New firmware for the Slampher

Some weeks ago I received a parcel from Itead. Previously, I had written about the Sonoff and they were kind enough to send me two more of their home automation products for me to review: the S20 Smart Socket I wrote about two weeks ago and the Slampher.

Slampher box

The Slampher comes in a simple cardboard box with no documentation at all… just visit their wiki!

The Slampher is kind of a Sonoff RF that sits before any light bulb with an E27 screw. As you can see in the header pic of this post it adds quite some length to the group. It’s a bit bulky and might not fit in every lamp. Off course the board layout is different from the Sonoff and it uses a JST131U-800D 1A triac instead of a relay to switch the bulb. Aside from that they are equivalent.

Continue reading

S20 Smart Switch

S20 Smart Socket

Since I discovered the Sonoff I’ve been thinking about embedding it inside a switch. I started looking for old power meters, timers,… I had at home but the Sonoff is a bit too long. Why didn’t they design a square board? I event bought a bulky Kemo STG15 case with socket.

Next I decided to design my own board. It is meant to be the “official” hardware for the ESPurna project so it’s called ESPurna too. It’s opensource hardware and available at the ESPurna project repository at Bitbucket. I have some boards already for the first iteration (version 0.1). They are mostly OK but I’m already working on a revision.

But then ITead’s released their S20 Smart Socket. It’s the Sonoff in a wall socket enclosure. Almost 100% what I wanted. And at 11.70€ it’s hard to beat. There are other wifi smart sockets available, mainly Orvibo and BroadLink (an SP2 Centros should be arriving home anyday now) but ITead’s is cheaper and you can easily re-flash it. Just solder a 4 pins header, connect it to your FTDI programmer, hold the S20 button, connect the programmer to your computer and flash. Done.

OK, not so fast. Why would I do that? Why would I change the stock firmware?

The answer for me is a mixed up of philosophy and practicity. But you are right. Let’s go step by step.
