Monteino Door Monitor

Some days ago I posted about the RFM69 to MQTT gateway based on the ESP8266 I am working on. Over these days I’ve been fine tuning the gateway at the same time I was migrating one of my home sensors to Monteino: the Door Monitor. The previous version was based on an XBee radio and has been on duty for almost 3 years and a half. Real life battery time has been around 3 months for a CR2032 coin cell, which is not bad at all, but still…

Aside from using a Monteino and a RFM69 868MHz radio instead of the XBee, I have reduced the components list by moving hardware logic to software logic. This means using sleeping capabilities of both the ATMega328 and the RFM69 and coding in a clever way to reduce awake time.

Continue reading

20160820_102049x

New firmware for the Slampher

Some weeks ago I received a parcel from Itead. Previously, I had written about the Sonoff and they were kind enough to send me two more of their home automation products for me to review: the S20 Smart Socket I wrote about two weeks ago and the Slampher.

Slampher box

The Slampher comes in a simple cardboard box with no documentation at all… just visit their wiki!

The Slampher is kind of a Sonoff RF that sits before any light bulb with an E27 screw. As you can see in the header pic of this post it adds quite some length to the group. It’s a bit bulky and might not fit in every lamp. Off course the board layout is different from the Sonoff and it uses a JST131U-800D 1A triac instead of a relay to switch the bulb. Aside from that they are equivalent.

20160820_103247x

The JST131U-800D triac in a TO-92 package is placed in the the center of the board

There are a number of reviews of the Slampher that focus in the basic usage or that go more in depth tearing it apart or flashing a custom firmware. As you can guess, I’m more interested in the later. I already exposed my reasons in my post about the S20 Smart Socket and this week it has become more apparent as a report from Bitdefender has uncovered a bug on a commercially available smart socket that would allow attackers to create a malicious botnet. An army of owned sockets!

We are only a few days away from the arrival of the ESP32 and the ESP6288 is still one of the kings of the IoT block, and a really a successful one. Itead choice of using Espressif chips on their home automation line of products make them a hackers dream.

There are a few firmwares available that will work on the Slampher, including my Espurna Firmware. Most of them have MQTT support and a web configuration portal. Some, like the Espurna, are light enough to support OTA with the 1Mb flash memory that the Sonoff or the Slampher have.

Flashing the Slampher

The Slampher and the Sonoff RF both have a 8bit EFM8BB10F2G-A-QFN20 microcontroller (from the EFM8 Busy Bee family) by Silabs that listens to the radio module messages and handles the on-board button. That button is tied to GPIO0 in the Sonoff TH or the S20 Smart Socket and it can be used to enter into flash mode upon boot. Same things does not happen on the Slampher.

EFM8BB1 in the Slampher

The EFM8BB1 is the little 3x3mm chip at the top right of the image, just by the testing pads.

The EFM8BB1 intercepts the button events so it can enter into “pairing mode” when the user double-clicks the button. In pairing mode it listens and stores a new radio code that will become the code to toggle on and off the switch from then on. But the curious thing is that if there is a single click event it just pulls down GPIO0 in the ESP8266 like the the button does in the non-RF versions. So Sonoff firmwares will work just the same except for:

  1. You cannot use the button to enter flash mode in the ESP8266 (since it’s a user firmware event that pulls GPIO0 down and no user firmware is running at boot time).
  2. You can’t use double click events on your firmware because these are intercepted by the EFM8BB1, unless they are more than about half a second away from each other.
  3. You can’t use long click events since the EFM8BB1 pulls GPIO0 down only on button release for about 125ms.

Issues #2 and #3 you will have to live with them. My Espurna firmware uses double click and long click events to enter AP mode and to reset the board respectively. That will not work on the Slampher. I could extend the double click interval in the DebounceEvent library from 500ms to 1000ms, but it won’t be very user friendly.

Issue #1 has different solutions. Scargill suggests to move resistor R21 to R20, so the button is now attached to ESP8266 GPIO0 (check the schematic at Itead wiki). Problem is that you lose the ability to pair your remote. Off course you could pair it first and then move the resistor but chances are that in the long run you will need to pair it more often than flash it, because you have OTA.

So my solution is to momentarily shortcut to ground the unpopulated pad of R20 that goes to GPIO0 and power the device at the same time. It’s not easy, you will need some practice and you will probably have to do it more than once. But at the end you will have a customized Slampher with fully working RF support.

20160820_110219x

Short to ground the R20 pad that goes to the ESP8266 while powering the board to enter flash mode

Off course I’m assuming you have a stable OTA-able firmware and that you have a testing platform (I have a Sonoff just for that). Also, you can add a new button between the pad and GND to flash the device in a more comfortable way.

The Slampher has a 4 pins header that brings out everything you need to flash it (except for GPIO0), counting from the little white mark onwards: VCC, RX, TX and GND. You just need to wire your favourite USB to UART board (an FTDI-like) and you are ready to go. Just remember: the ESP8266 requires 3V3, not 5V! And connect TX to your programmer RX and RX to TX. Then you will need to handle the board with care with another ground jumper wire touching the R20 right pad (check the images) while you disconnect and connect you FTDI board or the VCC cable.

Slampher flashing wiring

Somewhat hard to see but here you have my flashing set up… notice the additional black wire in the breadboard I use to pull down GPIO0 on boot

Radio codes

The radio receiver chip is a SYN470R by Synoxo in a 16 pin SOP package. This is a ASK/OOK RF transparent link (an “antenna-in to data-out” as the manufacturer says). It needs a microncontroller to act as a logic decoder. You can configure the bandwidth and it has a WAKEUP pin you can use to wake up your controller when there is a radio signal.

20160820_103334x

First I tried to pair it with my Avidsen remote without success. Then I used another remote I have for Noru radio sockets and it worked! Kind of… The red LED in the radio modules blinked while pairing it but not all the buttons worked. Only ON1, OFF2, OFF3 and 8H buttons on my Noru remote actually work with the Slampher. Weird.

RF socket remotes

The Noru remote is the one on the left

So I reviewed my own post about decoding radio signals but instead of using my Bus Pirate I give it a try to the RCSwitch library first, using the basic receiver example and adding some code to output “normalized” data strings, I started decoding the 4 buttons of the remote Itead is selling. This is the code I used:

#include <RCSwitch.h>;

RCSwitch mySwitch = RCSwitch();

void setup() {
  Serial.begin(115200);
  mySwitch.enableReceive(0);  // Receiver on inerrupt 0 =>; that is pin #2
}

void loop() {
  if (mySwitch.available()) {

    int value = mySwitch.getReceivedValue();

    if (value == 0) {

      Serial.print("Unknown encoding");

    } else {

      Serial.print("Received ");
      Serial.print( mySwitch.getReceivedValue() );
      Serial.print(" / ");
      Serial.print( mySwitch.getReceivedBitlength() );
      Serial.print("bit ");
      Serial.print("Protocol: ");
      Serial.print( mySwitch.getReceivedProtocol() );

      char binary[25] = {0};
      char tristate[13] = {0};
      int count = 0;
      int tri = 0;

      unsigned int * timings = mySwitch.getReceivedRawdata();
      for (int i=1; i<49; i=i+2) {           binary[count++] = (timings[i] > 500) ? '1':'0';
          if (count % 2 == 0) {
              if (binary[count-2] == '0') {
                 tristate[tri++] = (binary[count-1] == '0') ? '0' : 'F';
              } else {
                 tristate[tri++] = (binary[count-1] == '0') ? 'X' : '1';
              }
          }
      }

      Serial.print(" Binary: );
      Serial.print(binary);
      Serial.print(" Tristate: );
      Serial.println(tristate);

    }

    mySwitch.resetAvailable();

  }

}

The output of the 4 buttons from the Itead remote is:

Button Value Binary Tetrabits
A 11708433 101100101010100000010001 X10XXXX00F0F
B 11708434 101100101010100000010010 X10XXXX00F0X
C 11708436 101100101010100000010100 X10XXXX00FF0
D 11708440 101100101010100000011000 X10XXXX00FX0

As you can see they are 24 bit messages where the first 20 are the same for the 4 buttons and then there is only one bit set for the remaining 4 bits. The 4 buttons in the Noru remote that work have only 1 bit set in the last 4. That’s why the remote Itead sells has only 4 buttons. I still don’t know if I can use Itead’s remote with the Noru sockets since I never managed to know the relation between button codes (between ON and OFF buttons that control the same socket). But they don’t look compatible…

Note: one funny thing is that there is another EFM8BB1 microcontroller on the radio module. What? Maybe the radio decoding is done in this second chip while the one in the Slampher board is just responsible for the button and the GPIO0?

Wrapping up

The Slampher might be a bit bulky and it won’t fit in all the lamps (it does protrude from the livingroom lamp cover at home) but it’s a fine device for home automation. My criticism to the eWeLink app and my concerns about really owning the device still stand. But I will no doubt tell you: go buy one, flash it with your own firmware and enjoy.



20160819_002338x

RFM69 WIFI Gateway

Some 3 years ago I started building my own wireless sensor network at home. The technology I used at the moment has proven to be the right choice, mostly because it is flexible and modular.

MQTT is the keystone of the network. The publisher-subscriber pattern gives the flexibility to work on small, replaceable, simple components that can be attached or detached from the network at any moment. Over this time is has gone through some changes, like switching from a series of python daemons to Node-RED to manage persistence, notifications and reporting to several “cloud” services.

But MQTT talks TCP, which means you need some kind of translators for other “languages”. The picture below is from one of my firsts posts about my Home Monitoring System, and it shows some components I had working at the time.

Home WSN version 2

All those gears in the image are those translators, sometimes called drivers, sometimes bridges, sometimes gateways. Most of them have been replaced by Node-RED nodes. But not all of them. This is the story of one of those gateways.

Continue reading
